UAV Avionics Lab



UAV Avionics Lab was developed with exhaustive inputs from the Departments of Aerospace Engineering of IIT Kanpur and IISc Bangalore. The Lab has a baseline infrastructure for fabrication, assembly, and avionics development for Unmanned Aerial Systems. The Lab has received development funds from the Host Institute, MEITY, i-Hub, and ARDB-DRDO over time. The lab is equipped with a varying range of drones, avionics components, facilities for PCB prototyping, 3-D prototyping, mechanical prototyping, and space for boot camp conduction.

People


Equipments


Rugged Laptop

The GETAC S410 is a rugged laptop designed for use in demanding environments where durability and performance are crucial. It features a robust, shock-resistant design, built to withstand drops, vibrations, and extreme temperatures. The S410 is equipped with powerful processors, high-resolution displays, and long battery life, making it ideal for industries like field service, military, and construction. It also includes various ports and connectivity options for seamless data transfer and communication in challenging work conditions.

Workstation and Computers

The HP Z2 Workstation is a high-performance desktop workstation designed for professionals who require reliable computing power for tasks like 3D modeling, CAD, and video editing. It offers powerful processors, high-quality graphics, and ample storage options, making it suitable for demanding applications in fields such as engineering, architecture, and media creation. The Z2 Workstation is known for its stability, scalability, and expandability, ensuring that users can customize and upgrade components based on their specific needs.

Image Image
FDM 3D Printer

A creative 3D printer is a versatile and innovative machine that allows users to bring their digital designs to life in three dimensions. By using materials like plastic, resin, or metal, it builds objects layer by layer based on a 3D model, making it ideal for prototyping, artistic expression, and custom creations. With enhanced precision, customizable features, and the ability to produce intricate details, a creative 3D printer offers endless possibilities for design, art, and engineering projects.

SLA Curing Chamber

An SLA curing chamber is a specialized device used to further cure and harden 3D-printed objects made with SLA (Stereolithography Apparatus) technology. After an object is printed, it typically needs additional exposure to UV light or heat to fully solidify and reach its final strength and durability. The curing chamber provides a controlled environment with consistent UV light or heat to ensure even and efficient curing of the resin. This process helps to enhance the mechanical properties, surface finish, and stability of the printed object, making it suitable for functional applications.

Universal Bender

The 20012 Universal Bender is a versatile tool designed for bending metal rods, wires, and tubes with precision. It features adjustable settings to accommodate various materials and bend angles, making it ideal for use in laboratories and small-scale fabrication.

Image Image
Angle Cutter

The band saw is equipped with a powerful 1100W motor, ensuring efficient and effective cutting across various materials.Pillar drill bench. It is designed to cut through different types of materials, including wood, metal, and plastic. This makes it suitable for a wide range of applications. The band saw offers precise and accurate cuts, thanks to its sharp teeth and stable cutting platform. This allows for clean and smooth cuts, minimizing the need for additional finishing work.

Vertical Cutting machine

VOLTZ VZ-BS0903 1.6A 9-Inch Band Saw The newly launched 1.6A 1400RPM & 10.5M/SEC low noise induction motor bandsaw, which is very suitable for home and DIY use. 2nd img VOLTZ Band Saw features high performance and high reliability. Work smarter,faster and better with VOLTZ 1.6-Amp 9-Inch Band Saw. Benchtop Band Saws for Wood offers a lightweight,compact design that is easy to use with less fatigue. TechnicalMetal Shear cutter. Specs Motor: 1.6A Motor Speed: 1400RPM Blade Speed: 10.5M/SEC Table size: 12inch x 12inch Saw blade width: 1/8",1/4",3/8" Saw blade length: 59-1/2" (1511mm) Cutting capacity throat: 9" Sawdust port: 2-1/2".

Benchtop Grinder

A bench grinder is a stationary power tool used for grinding, sharpening, and polishing metal objects. It consists of a motor that drives two grinding wheels, typically made of abrasive materials like aluminum oxide or silicon carbide. Bench grinders are commonly used in workshops and garages for tasks such as sharpening tools, removing rust, and shaping metal. They come in various sizes and can be equipped with additional attachments, like a wire brush or polishing wheel, for increased versatility.

Drill Machine Tool kit

The Bosch GSB 10 RE is a compact and powerful drill machine designed for both drilling and screwdriving tasks. It features a 500W motor, making it suitable for light to medium-duty tasks, and is equipped with a 2-speed gearbox for versatile control. The GSB 10 RE is designed with a robust build and ergonomic handling for comfort during extended use. It is ideal for DIY projects, home repairs, and light construction work. This drill machine typically comes with a keyless chuck, making bit changes quick and easy.

Metal Sheet Cutter

Heavy duty metal sheet cutter can be used for cutting strong material sheet to be used for mechanical fabrication of drone parts.

PCB Assembly tools

The Soldron 878D is a versatile, high-performance soldering station commonly used for electronic assembly and repair. It features both a soldering iron and a hot air rework gun, making it ideal for tasks like soldering, desoldering, and surface mount component work. The station allows precise temperature control, ensuring effective and safe soldering. With adjustable airflow for the hot air gun and a range of temperature settings, the Soldron 878D is popular among hobbyists, technicians, and professionals for its reliability and ease of use in various soldering applications.

Image Image
RC Flight Simulator

The Phoenix RC Flight Simulator supports real RC interfaces, allowing users to connect their actual remote control transmitters to the simulator. This feature provides a more realistic flying experience, as pilots can practice with the same controls they use for their real RC aircraft. By using a compatible interface (such as a USB cable or specialized dongle), the simulator replicates the feel and handling of real-world flying, making it an invaluable training tool for both beginners and experienced RC pilots.

GNSS Receiver Dev Kit

NT1068.2 GNSS RF front-end with xilinx PicoZed FPFA on Avnet Carrier card can be used for development of baseband signal processing for GNSS receiver and anti-jamming/anti-spoofing techniques for UAVs.

GNSS RF Front End

NT1068.2 USB EVK with Quad-band GNSS antenna can be used for GNSS signal acquisition.

MIMO FPGA Dev Kit

Xilinx zc706 and dual AD9361 RF front-end based 4x4 MIMO devkit can be used for development of baseband signal processing algorithms for wireless systems to be used in different aerial platforms


Inventory


Hexacopters

Medium size hexacopter


Large size spraying hexacopter

Quadcopters

Medium size qaudcopter


Small size quadcopter


Very small size quadcopter

RC Controllers

H12 advance RC Remote with display


Multi-channel servo RC remote

Software Defined Radio

Adalm Pluto SDR kit with FPGA programming option

Ultrasonic Ranging Module

Inhouse developed ultrasonic ranging module for compact formation based swarming drones

Batteries and Pixhauk Module

Flight Controller and LiPo battery (sample)
